Genel Özellikler
Polyester tents are designed to be used for disaster areas, accommodation for far post structures for maintenance, and warehouse activities. The closed area of 40 m 2 the advantages of Inflatable arches, such as modularity, minor load, ease of set-up (2 persons 15 minutes inflation with compressor) should be taken into consideration.
All the bottom are covered with polyester material to isolate the inner surrounding from the outer affects such as molding, water, snow. Central modules can be redesigned with windows, and connection doors to other inflatable structures, according to different requirements, and big doors can be designed for vehicles entering structures, and 4,5,6 Arch versions can be designed for enlarging the structure according to your requirements.
General Assets
- Modularity
- Functional
- Self Support
- Fast Set-up
- Less Load
- No vertical Poles
- Minor Maintenance
- Do not require Inflation all the time
- Maintenance can be done with isolation
Use
- Hangar for small vehicles
- Shelter
- Briefing
- Stand for Advertising
Teknik Özellikler
| TECNICAL SPECIFICATIONS | |||
| Material | Polyester | ||
| Technology | Sewing Heat welded | ||
| Inflation Time | 15 minutes | ||
| Color | Green-Blue-White | ||
| Dimensions | Length | Width | Height |
| 800 cm | 600 cm | 290 cm | |
| Inflatable Arch Radius | 50 cm. | ||
| Area | 48 m² | ||
| Volume | 98 m³ | ||
| Doors | 4 | ||
| Windows | 4 pcs. Roll up with Mosquito net | ||
| Inflation Valves | 1 for each Arch | ||
| Optional Accessories | Electrical connections, Inner Isolation, Heating, cooling, Sun shade | ||
| Standard Accessories | Carrying Case, Hammer, Manuel pump, poles, user manuals, repair patches. | ||
